Image Reject Mixer, 200-350 MHz
Model: IR-10-303
View All Image Reject Mixers
Pulsar iq network IR-10-303 covers the range 200-350 MHz, while our complete line of iq networks cover frequency ranges up to 16 GHz. Any Pulsar model can be customized to suit your specific performance or package requirements at little to no extra cost. Pulsar is ISO-9001 certified and ITAR registered.
- Specifications
- Support
Outline 303
1.00" x 1.00" x 0.15"
| Name: | IR-10-303 |
| LO Frequency (+10 dBm): | 200-350 MHz |
| RF Frequency (-10 dBm): | LO ± IF (20 MHz) |
| LO Power: | 10 dBm nom. |
| Conversion Loss: | 9.0 dB max. |
| 1 dB Compression Point: | +3 dBm min. |
| Image Rejection: | 25 dBc min. |
| Connector Type: | Pin |
- Image rejection minimum applies to IF1 when RF < LO frequency.
- Image rejection minimum applies to IF2 when RF > LO frequency.
-
Custom performance and package requirements available.
